HECO-TOPIX-plus 4,5 x 40, fitting screw, countersunk head, HECO-Drive, VFT, A3K, 500 pcs.
The fitting screw for the professional
The HECO-TOPIX-plus fitting screw is ideal for the fastening of strips, tilt-turn fittings, locking parts and bearings in wood or plastic materials. Its specially for metal fittings adapted head pitch, enables quick insertion without damaging the fittings surface. In addition, the head pitch ensures an ideal braking effect and makes annoying slipping almost impossible. Especially when working with thin materials the HECO-TOPIX-plus fitting screw can’t be topped. The patented HECO-TOPIX tip allows a splitting-free insertion even in lowest profiles without pre-drilling.
Technical data
- Diameter, d [mm]
4,5
- Length, l [mm]
40
- Material
carbon steel
- Head form
fitting screw, countersunk head
- Headdiameter, dk [mm]
7,9
- Recess
HECO-Drive
- Size of recess
HD-20
- Thread
variable full thread
- Thread length, lg [mm]
35
- Surface
bright zinc plated, A3K
Features & benefits
- No damage to the fitting
- Braking effect of the head prevents the screw from being overtightened
- HECO-TOPIX tip does away with the need for pre-drilling, reduces the risk of the wood splitting and enables narrow edge and centre distances.
- GripFit: One-handed working possible thanks to the HECO-Drive. Holds the stainless steel screws securely on the bit.
- PerfectPitch: Optimal thread pitch for every screw length. Perfect performance for any wood application.
- Chromium (VI)-free coating
- Approved and monitored product
Technical data
- Diameter, d [mm]
4,5
- Length, l [mm]
40
- Material
carbon steel
- Head form
fitting screw, countersunk head
- Headdiameter, dk [mm]
7,9
- Recess
HECO-Drive
- Size of recess
HD-20
- Thread
variable full thread
- Thread length, lg [mm]
35
- Surface
bright zinc plated, A3K
