Circular saw blade HM 250 x 2.2/1.8 x 30 mm, Z= 100

Ursprünglicher Preis war: 227,25 €Aktueller Preis ist: 113,62 €.

Artikelnummer: K-111050-250-010 Kategorien: ,

Beschreibung

Carbide tipped circular saw blade for aluminium, plastics and non-ferrous metals

Sizing and cross cutting, preferably for automatic feed.

For table saws, battery driven saws, automatic cross cut saws and CNC maching centers.

Technical data

  • D 250 x 2.2/1.8 x 30 mm
  • Teeth Z= 100 TFPD (Triple chip / flat tooth thin positive) with 5° angle of rake
  • Side holes for driving pins
    2/7/42 + 2/9/46.4 + 2/10/60 + 2/11/63 + 2/12/64
  • Recommended speed Ø 250 mm
    4200-4500 rpm

Features & benefits

  • Great for cutting non-ferrous metals like aluminium, copper and brass.
  • Great for cutting plastics, acrylics, duro- and thermoplastics.
  • Good for cutting high-pressure-laminate solid boards/facade panels like Trespa, Resopal, Duropal, Formica, Kronospan and Decodur.
  • Good for cutting mineral/acrylic bound solid boards like Corian, Noblan, HI-Macs, Staron, Rausolid and Varicor.
  • Due to positive cutting angle preferably for automatic feed (manual feed is also possible).
  • Higher cutting values, less waste, less wear / energy consumption of the machine and much less effort with manual feed due to thin cutting width.
  • Main body made of first-class steel quality and laser-cut.
  • Special HM teeth, adapted to each type of saw.
  • Perfect grinding, lowest tolerances (H7) and finest grain of the carbide guarantee excellent cutting quality.
  • Absolutely precise, low-noise and smooth running.
  • Honed drillings.
  • High-quality multiple soldering for more stability and protection against damage.
  • Optionally we recommend the purchase of a Industrial cleaner TR-CLEAN-500 to clean and maintain the saw blades. In addition, when cutting metal, the use of a lubricant such as TR-TRENDIWAX significantly increases the service life.

Technical data

  • D 250 x 2.2/1.8 x 30 mm
  • Teeth Z= 100 TFPD (Triple chip / flat tooth thin positive) with 5° angle of rake
  • Side holes for driving pins
    2/7/42 + 2/9/46.4 + 2/10/60 + 2/11/63 + 2/12/64
  • Recommended speed Ø 250 mm
    4200-4500 rpm
